Lap Counter electronic

Egun - StartTime V acoustic start device

Article: 3481.931
Main unit dimensions: 376 x 215 x 245mm w/o Connectors
Microphone dimensions: 118 x 25 x 80 mm. + 7 meter cable
E—GUN dimensions 280 x 35 x 140 mm + 7 meter cable
Alarm “low battery”: Yes, 4 levels indicated as battery symbol (Empty, Low, Medium, Full)
Protection class: IP41
Power: Built in 12 Volt / 7 Ah Sealed lead—acid battery
Standby time: 24 Hours (1000 starts). After this, the unit should still be operable for 1 hour.
The self—discharge time is approximately 12 months if not in use.
An external 12V Lead/Acid battery (car battery) connected to the charger input, could be used if extended operation time is needed.
Charger: Max. initial current: 1.0 Ah (only for use in dry environment).
Speakers: Load 3.2 — 16 Ohms
Output speakers: @13.2 Volts, 3.2 Ohms, 1 kHz Typical: 2 * 13 Watt with < 10 % Distortion Maximum: 2 * 19 Watts with 10 % Distortion
Storage temperature: —20ºC to +65ºC
Working temperature: —10ºC to +65ºC
Relative humidity: (20%—80%) without condensation
Manufacturer Swiss Timing (Switzerland)

Start Transducer OST4

Article:3431.901
Manufacturer: Swiss Timing
Model: OST4

Electronic distance measurement system

Article: 3142.902
Manufacturer: (Switzerland)
Category: Refereeing and timing systems for athletics
Specifications:
Weight : 6.5 kg
Battery life : 6 — 8 hours
Maximum range : 3000 m (prism)
250 m (reflective tape), 150 m (reflectorless)
Minimum range : 1.5 m
Accuracy : 2 mm
Measuring time : 1.5 s
Display: colored LCD
Interface language : selectable
Data connection : RS232 or optional Bluetooth
Operating temperature : —20 to 50°C (operating)
Storage temperature : —40 to 70°C (storage)
Humidity : 95% (non—condensing)
Sertifcates: IAAF Approved
