World athletics aluminum hammer cage with ground sleeves

Article: AVDM1099

Aluminium hammer throw cage with ground sleeves, World Athletics certified.

Description:

The hammer throw cage made of anodised oval aluminium is characterised by high quality, durability and safety. It is used at all major national and international championships.

Each aluminium upright is reinforced with an internal sleeve up to a height of 2,40 m to prevent break points.

The nets made of moisture-resistant polypropylene cord Ø5 mm with a 40 × 40 mm mesh size, certified according to EN-1263-1, are installed using a “floating” method to eliminate the risk of ricochet towards the athlete in accordance with World Athletics rules. The net is raised and lowered using nylon rollers. The system is supplied with ground sleeves and nets.

Advantages:

● High strength and durability of the construction

● Rear and front aluminium uprights with reinforcement

● “Floating” nets, certified according to EN-1263-1

● Easy raising and lowering of the net

● Compliance with World Athletics requirements.

Included Components:

● Anodised aluminium uprights (oval profile) — 6 pcs., height 7,20 m

● Anodised aluminium uprights (oval profile) — 4 pcs., height 10,20 m, with reinforced support legs

● Aluminium protective panels/doors — 2 pcs., height 10 m, on stable bases with 2 rubber wheels Ø260 mm each

● Adjustable galvanised steel crossbars — 11 pcs.

Technical Specifications:

● Type — hammer throw cage

● Construction — aluminium

● Installation — permanent, with ground sleeves

● Net installation — “floating”

● Certification — World Athletics

Materials:

● Uprights and doors — anodised aluminium, oval profile

● Crossbars — galvanised steel

● Nets — polypropylene Ø5 mm, EN-1263-1

● Door wheels — rubber Ø260 mm

Dimensions:

● Ground sleeves: 700 mm and 1000 mm

● Main net — 24500 × 7300 mm

● Braided ropes — 15000 mm and 20000 m

● Upright height — 7200 mm and 10200 mm

Production:

● EU

Sport: Athletics

Category: Sports equipment

Subcategory: Throwing sectors (hammer)

Discipline: Hammer throw
